SD-40-6040
SD SERIES | CO2 LASER MACHINE
Compact Size. Flexible Installation.
The Rabbit Laser USA SD-40-6040 is a compact commercial CO2 laser engraver and cutter designed for makers, schools, and small businesses. Its 23.62" × 15.75" work area handles detailed engraving, custom products, and small production runs, while the modular cabinet can be separated to make moving the machine through tight spaces easier.
Work Area: 23.62" × 15.75" (600 × 400 mm)
Laser Power: 40W standard, 60W optional
Cabinet: Modular, separable design
Support: Lifetime U.S.-based technical support
Built for Real Projects
Compact Workspace. Professional Capability.
The 23.62" × 15.75" work area is well suited for personalized gifts, signs, awards, decorative pieces, and small production batches without requiring a large workshop.
Modular Cabinet Design
The separable cabinet makes moving the machine into basements, classrooms, small shops, and other spaces with restricted building access more manageable.
Engrave and Cut with Confidence
Create detailed engravings and custom-cut components using compatible materials such as wood, acrylic, leather, paper, and fabric. The motorized Z-axis accommodates different material heights for a wider range of projects.
What's Included
Essential equipment included with your SD-40-6040.
40W sealed glass CO2 laser tube standard, with an optional 60W upgrade
CW-3000 water-cooling unit with flow sensor safety system
Exhaust fan, ducting, and air assist pump
Honeycomb bed, metal slats, and vacuum table
LightBurn laser software
Important Purchasing Information
The advertised machine price does not include delivery, installation, or training. Optional on-site services depend on your location and are quoted separately.
Technical Specifications
Model
SD-40-6040
Work Area
23.62" × 15.75" (600 × 400 mm)
Laser Source
Sealed glass CO2 laser tube
Power Options
40W standard / 60W upgrade
Cabinet Construction
Modular, separable cabinet
Electrical Supply
110 VAC
Cooling System
CW-3000 water-cooling unit with flow sensor safety system
Work Surfaces
Honeycomb bed, metal slats, and vacuum table
Motion System
Microstepping motor system
Listed Maximum Engraving Speed
1,000 mm/s
Z-Axis
Motorized, approximately 9.45" usable height
Positioning Precision
Listed at less than 0.01 mm
Scanning Resolution
Up to 1000 DPI
Software
LightBurn
Listed Machine Weight
Approximately 309 lb (140 kg)
See Laser Engraving in Action
See a laser project demonstrated by Rabbit Laser USA.
Project Inspiration
Explore creative projects made possible with laser engraving and cutting, from personalized gifts to custom signs and decorative pieces.
Project results depend on materials, machine settings, and accessories used.
Support That Stays With You
Your relationship with Rabbit Laser USA doesn't end when you purchase your machine.
We provide lifetime U.S.-based technical support, including phone and remote assistance. Whether you're learning LightBurn, preparing for a new project, or troubleshooting an issue, our team is here to help.
Have Questions Before Ordering?
Not sure whether the modular SD-40-6040 or rigid DL-40-6040 is the better choice for your workspace?
Compare the 6040 CO2 Laser Machines
Need help selecting the right laser power or arranging delivery and on-site services? Tell us about your workspace and the projects you want to create.
