The Reci 90W CO2 laser tube is a water-cooled glass laser tube designed for compatible CO2 laser engraving and cutting machines. With a rated output of 90W and a maximum output of 100W, it provides the laser power needed for a range of engraving and cutting applications.
Measuring 1250mm in length and 80mm in diameter, this tube matches the published dimensions of the Reci W2 series. Its sealed glass construction and water-cooled design make it a replacement option for appropriately equipped CO2 laser systems.
Manufacturer:
Reci
Rated Power:
90W
Maximum Power:
100W
Tube Length:
1250mm
Tube Diameter:
80mm
Cooling:
Water-cooled
Key Features
90W Rated Output
Designed for 90W rated output with a manufacturer-specified maximum of 100W, making it suitable for compatible machines used in engraving and cutting applications.
Reci Glass Laser Tube Construction
Reci's W-Series uses a metal-to-glass joining process designed to improve structural stability and consistency in laser output.
Water-Cooled Operation
Circulating water helps regulate operating temperatures and protect the laser tube from excessive heat. Proper cooling is essential for dependable performance and service life.
Replacement Laser Component
Designed for compatible CO2 laser systems equipped with the appropriate mounting space, high-voltage power supply, and water-cooling system.
Technical Specifications
Manufacturer
Reci
Specification Reference
Reci W2 Series
Rated Output Power
90W
Maximum Output Power
100W
Tube Length
1250mm
Tube Diameter
80mm
Recommended Current (W2)
24mA
Wavelength
10.6 micrometers
Cooling Method
Circulating Water
Application
CO2 Laser Engraving & Cutting
SKU
220
Compatibility & Installation
This Reci laser tube is intended for compatible CO2 laser systems that accommodate its physical dimensions and electrical requirements.
Before purchasing, compare the manufacturer model, tube length, diameter, power rating, power supply, and cooling connections with your existing laser tube. Matching wattage alone does not guarantee compatibility.
Important Installation & Safety Information
CO2 laser tubes operate at dangerous high voltages and produce invisible laser radiation. Replacement, electrical connections, and optical alignment should be performed by qualified personnel following the equipment manufacturer's procedures.
Always maintain proper cooling water circulation. Never operate the laser tube without adequate cooling, and protect the cooling system from freezing.
Follow the manufacturer's specified current and cooling requirements. Operating beyond the recommended limits can damage the tube or shorten its service life.
Need Help Choosing the Right Laser Tube?
Rabbit Laser USA provides technical support to help identify compatible replacement laser tubes. If you're unsure which tube your machine requires, contact our team with your machine model and existing tube specifications before ordering.
