The PYF08A relay base
is an 8-position socket designed to provide a secure electrical connection for compatible plug-in control relays. Commonly used in industrial control panels, automation equipment, and machine electronics, this socket allows a compatible relay to be removed or replaced without disconnecting the individual circuit wires.
Designed for compatible MY2-series, two-pole relays, the PYF08A features screw-terminal connections and a DIN rail mounting design. It is a practical replacement component for maintaining compatible electrical control systems and laser machine electronics.
Key Features
8-position plug-in relay socket
Designed for compatible MY2 and MY2N series relays
Supports two-pole (DPDT) relay configurations
Screw-terminal electrical connections
DIN rail or compatible screw mounting
Removable relay design for convenient servicing
Compact housing for electrical control panels
Suitable for compatible machine control and automation circuits
Product Specifications
Model
PYF08A
Series
PYF
Product Type
Relay Socket / Base
Socket Positions
8
Relay Configuration
2-Pole / DPDT
Connection Type
Plug-In Relay
Wire Termination
Screw Terminals
Mounting Method
DIN Rail / Screw Mount
Compatible Relay Family
MY2 / MY2N Pattern Relays
Housing Color
Black
Application
Electrical Control and Automation Circuits
Quantity
One Relay Base (Socket Only)
Compatibility & Installation
The PYF08A socket is intended for compatible MY-series plug-in relays using the appropriate 8-pin configuration. Before ordering, verify the relay model, pin arrangement, mounting requirements, and electrical ratings against your existing equipment.
Important:
This listing is for the relay socket only. The relay itself is not included. The PYF08A and PTF08A sockets are designed for different relay families and should not be treated as interchangeable.
Disconnect equipment power before installation or replacement. Confirm terminal identification and wiring against the appropriate relay documentation. Installation should be performed by a qualified technician.
Rabbit Laser USA Support
Not sure whether this relay socket is compatible with your laser machine? Contact Rabbit Laser USA with your machine model or the part number from your existing relay. Our technical support team can help identify the correct replacement.
