The Omron LY2N-J
is a general-purpose electrical relay designed for compatible laser machine control circuits and industrial electrical systems. It uses a 24VDC operating coil
to control two independent sets of switching contacts.
Featuring a double-pole, double-throw (DPDT) contact arrangement, this relay allows a low-voltage control signal to switch connected electrical circuits. Its transparent housing provides visibility of the internal components, while the integrated LED indicator helps technicians identify when the relay coil is energized.
The standard 8-pin plug-in design allows convenient installation and replacement using a compatible relay socket, making the LY2N-J a practical replacement component for equipment requiring this specific relay configuration.
Important:
Relays with similar appearances may have different coil voltages, terminal arrangements, or contact ratings. Verify the original relay specifications before ordering.
Key Features
24VDC Operating Coil:
Designed for compatible 24-volt DC control circuits.
DPDT Configuration:
Two independent changeover contact sets for flexible electrical switching.
8-Pin Plug-In Design:
Allows installation into a compatible relay socket for easier replacement.
Built-In LED Indicator:
Provides a visual indication when the relay coil is energized.
Transparent Housing:
Allows visual inspection of the internal relay mechanism.
10A Rated Carry Current:
Suitable for electrical applications within the manufacturer's specified ratings.
Silver-Alloy Contacts:
Designed for dependable electrical switching.
Replacement Component:
Suitable for compatible laser machine control systems and industrial automation equipment.
Product Specifications
Manufacturer
Omron
Model
LY2N-J
Product Type
General-Purpose Plug-In Relay
Coil Voltage
24VDC
Contact Configuration
DPDT (Double-Pole, Double-Throw)
Number of Poles
2
Number of Pins
8
Rated Carry Current
10A
Maximum Contact Voltage
250VAC / 125VDC
Coil Resistance
Approximately 650 Ohms
Coil Current
Approximately 36.9mA
Coil Power Consumption
Approximately 0.9W
Contact Material
Silver Alloy
Operation Indicator
Built-In Green LED
Housing
Transparent Protective Case
Mounting Style
8-Pin Plug-In Socket
Approximate Dimensions
21.5 x 28 x 36mm
Quantity Included
1 Relay (Socket Not Included)
Rabbit Laser USA SKU
333
How the Relay Works
The LY2N-J uses an electromagnetic coil to operate two separate sets of electrical contacts. When the 24VDC coil is energized, the internal switching mechanism changes the position of both contact sets.
Each contact set includes:
Common (COM):
The shared connection for the switching circuit.
Normally Closed (NC):
Connected to common when the relay coil is not energized.
Normally Open (NO):
Connected to common when the relay coil is energized.
The built-in LED provides a convenient visual indication of coil energization, which can assist with troubleshooting machine control circuits.
Note:
An illuminated LED does not confirm that the relay contacts are operating correctly. Contact operation and connected equipment should be tested separately when troubleshooting.
Compatibility
This relay is intended for equipment requiring an Omron LY2N-J or an approved equivalent with a 24VDC coil, DPDT contacts, and the corresponding 8-pin terminal arrangement.
The relay is designed for use with compatible LY-series relay sockets, including the PTF08A Relay Base (Rabbit Laser USA SKU 330), subject to verification of the socket and wiring configuration.
Before ordering, compare the replacement relay with your existing component:
Manufacturer and model number
24VDC coil requirement
DPDT contact arrangement
8-pin terminal configuration
Electrical contact ratings
Physical dimensions and socket fit
Coil polarity and indicator requirements
Wiring diagram printed on the original relay
Important:
A 24VAC relay is not a direct replacement for this 24VDC model. Relays with matching dimensions may still have different electrical specifications.
Relay socket sold separately.
Confirm compatibility before purchasing a replacement socket or relay.
Installation & Safety
Turn off and disconnect the laser machine from its electrical power source before replacing the relay.
Verify the replacement relay's coil voltage, contact ratings, and terminal arrangement.
Inspect the relay socket for heat damage, corrosion, or loose electrical connections.
Align the relay pins correctly with the socket before installation. Do not force the relay into place.
Follow the terminal wiring diagram and any polarity requirements marked on the relay.
Confirm the relay and connected control circuit operate correctly after installation.
If a replacement relay overheats, chatters, or fails repeatedly, troubleshoot the connected circuit before installing another relay.
Safety Note:
Electrical components inside a laser machine may carry hazardous voltages. Repairs should be performed by qualified personnel familiar with electrical control systems. Never bypass machine safety interlocks or protective circuits.
Need Help Finding the Right Replacement Relay?
Rabbit Laser USA supplies replacement electrical components, relays, controllers, and parts for CO2 laser machines. If you're unsure whether the Omron LY2N-J is compatible with your equipment, contact our team with your machine model and clear photographs of the existing relay and socket.
