Main Power Key Switch – 22mm Panel Mount

This Main Power Key Switch is a key-operated electrical control switch designed for compatible CO2 laser engraving and cutting machines. It provides a convenient way to control machine functions while restricting operation to someone with the appropriate key.

Designed to fit a 22mm panel opening, the switch features a metal-faced key cylinder, black housing, and rear-mounted electrical contact assembly. Its compact design makes it suitable for replacing an existing keyed control switch in compatible laser machine control panels.

A key-operated switch can help prevent casual or unintended activation by requiring a key to change the switch position. The actual electrical function depends on the contact configuration and machine wiring.

Important: Verify the switch's contact arrangement, operating positions, key-removal behavior, and electrical ratings before ordering. Similar-looking key switches may operate differently.

Key Features

• Key-Operated Control: Requires a matching key to change the switch position.
• 22mm Panel Mount: Designed for installation in compatible 22mm control-panel openings.
• Metal-Faced Key Cylinder: Features a silver-colored face with a slotted key opening.
• Rear Contact Assembly: Electrical contact components connect the switch to a compatible control circuit.
• Compact Design: Suitable for control panels with compatible mounting space and electrical connections.
• Machine Control Application: Can be used for compatible keyed enable or power-control functions.
• Replacement Component: Intended to replace an existing key switch with matching mechanical and electrical specifications.

Product Specifications

Product Type	Key-Operated Control Switch
Switch Style	Rotary Key Switch
Mounting Diameter	22mm (Approx. 0.87 in.)
Mounting Style	Panel Mount
Operator Type	Key-Operated Cylinder
Front Finish	Silver and Black
Rear Assembly	Modular Electrical Contact Block
Contact Configuration	Verify Against Original Switch
Operating Positions	Requires Verification
Application	Compatible Laser Machine Control Circuits
Quantity Included	1 Switch Assembly; Confirm Supplied Key Count
Rabbit Laser USA SKU	204

How a Key Switch Works

A key-operated control switch changes the state of an electrical circuit when its key is turned to a selected position.

In a compatible laser machine, this type of switch may be used to enable or disable a control circuit, depending on the machine's electrical design.

Key switches are available with different electrical contact arrangements:

• Normally Open (NO): The contact remains open until the switch reaches its activating position.
• Normally Closed (NC): The contact remains closed until the switch reaches its activating position.
• Multiple Contact Blocks: Some assemblies operate more than one electrical circuit through the same key mechanism.

Some key switches maintain their selected position, while others return automatically when the key is released. Key-removal positions may also vary between models.

The replacement switch must match the original component's operating action and electrical contact arrangement.

Compatibility

This key switch is intended for compatible CO2 laser engraving and cutting machines using a matching 22mm panel-mounted key-operated control switch.

Before ordering, compare the replacement with your existing switch:

• 22mm mounting hole diameter
• Key cylinder and bezel dimensions
• Switch operating positions
• Maintained or spring-return operation
• Positions where the key can be removed
• Normally open and normally closed contact arrangements
• Number and type of contact blocks
• Electrical voltage and current ratings
• Terminal identification and wiring configuration
• Available mounting depth behind the control panel

Important: A 22mm mounting diameter does not guarantee compatibility. Different key switches may have identical mounting dimensions but different contact configurations or operating functions.

Verify the replacement against the original switch and your laser machine's electrical documentation before installation.

Installation & Safety

• Disconnect and isolate the laser machine from its electrical supply before beginning installation.
• Verify that all affected circuits are de-energized before handling wiring or electrical terminals.
• Document the existing wiring and terminal connections before removing the original switch.
• Confirm that the replacement has the correct mounting diameter, contact blocks, and electrical ratings.
• Securely mount the switch in the control panel using its appropriate mounting hardware.
• Connect the terminals according to the machine's approved wiring diagram.
• Ensure all electrical connections and contact-block components are properly secured.
• Test the key positions and associated machine-control functions before returning the equipment to service.

Safety Note: A key-operated control switch is not a substitute for an approved electrical disconnect, emergency-stop circuit, or lockout/tagout procedure.

Removing the key does not necessarily disconnect electrical power from every circuit inside the machine.

Installation should be performed by someone qualified to work with electrical control systems. Incorrect wiring or incompatible switch contacts can cause unexpected equipment operation, electrical shock, or component damage.
