Main Door Magnetic Reed Safety Switch – 12-Inch Wire
This magnetic reed switch is a replacement door-position sensor for compatible CO2 laser engraving and cutting machines. Designed for use with an existing door interlock system, the switch responds to a nearby magnet, allowing the machine's control system to detect changes in the main door's position.
Featuring a compact black housing, two slotted mounting holes, and a 12-inch wire lead, this switch provides a straightforward replacement option for compatible laser machine door sensors. Its magnetic operation allows the door position to be detected without direct mechanical contact between the switch and its matching magnet.
Key Features
Magnetically activated reed switch
Designed for compatible laser machine door interlock systems
12-inch (approximately 305mm) wire length
Two-wire electrical connection
Compact rectangular black housing
Two slotted mounting holes for positioning and adjustment
Non-contact magnetic door-position detection
Replacement option for compatible main door sensors
Product Specifications
Product Type
Magnetic Reed Switch
Primary Application
Main Door Position Detection
Detection Method
Magnetic Actuation
Wire Length
12 in (305mm), Listed
Electrical Connection
2-Wire Leads
Wire Termination
Stripped Wire Ends
Mounting Style
Two Slotted Mounting Holes
Housing Color
Black
Compatibility
Select CO2 Laser Machines with Matching Magnetic Door Sensor Systems
Compatibility & Installation
This replacement switch is intended for compatible laser machines using a magnetic reed switch to monitor the main door. When connected to a properly configured interlock system, changes in the switch state can signal the machine's controller that the door has been opened or closed.
Before ordering, compare the existing switch's dimensions, mounting-hole spacing, wire length, magnetic activation requirements, and normally open or normally closed contact configuration.
Important Safety Information:
This component must be matched to the machine's original door interlock requirements. A replacement reed switch alone does not establish or certify the safety performance of the complete machine.
Disconnect equipment power before installation. Mount the replacement switch in the correct position, verify alignment with the corresponding magnet, and connect the wiring according to the machine's electrical documentation.
After replacement, verify that the door interlock responds correctly when the door is opened and closed. Do not operate the laser with a bypassed, damaged, or improperly functioning door interlock.
Rabbit Laser USA Support
Not sure whether this magnetic door switch is the correct replacement for your laser machine? Contact Rabbit Laser USA with your machine model or a photo of your existing switch. Our technical support team can help you verify compatibility and installation requirements.
