CO2 Laser Red Dot Pointer Module – 5V DC (12 x 22mm)
This red dot laser pointer module provides a visible positioning reference for compatible CO2 laser engraving and cutting machines. Because the CO2 laser beam is invisible to the human eye, a red dot pointer helps operators identify a reference point when positioning materials on the work surface.
Measuring 12mm in diameter and 22mm in length, this compact module operates on 5V DC power. It is suitable for replacing an existing pointer or installing a positioning aid on a machine with compatible mounting and electrical connections.
Product Type:
Red dot laser pointer module
Operating Voltage:
5V DC
Module Diameter:
12mm
Module Length:
22mm
Application:
Compatible CO2 laser positioning systems
Key Features
Visible Positioning Reference
Projects a visible red dot onto the work surface to assist with material positioning and identifying a reference location.
12mm Module Diameter
Designed for mounting arrangements that accommodate a 12mm diameter laser pointer module.
5V DC Operation
Operates using a compatible regulated 5V DC power source or suitable machine connection.
Replacement or Retrofit Component
Can replace a matching red dot pointer module or serve as a positioning aid when the machine supports the required mounting and electrical connections.
Technical Specifications
Product Type
Red dot laser pointer module
SKU
222
Operating Voltage
5V DC
Module Diameter
12mm
Module Length
22mm
Pointer Type
Visible red dot
Application
Compatible CO2 laser positioning systems
Check Compatibility Before Ordering
Confirm that your laser machine uses a 12mm diameter pointer module and provides a compatible mounting location and 5V DC power connection. This 12mm module is not a direct fit for holders designed exclusively for 10mm pointers.
Important:
The red dot pointer is non-collinear with the CO2 laser beam. It follows a separate optical path and must be adjusted to provide an appropriate positioning reference. The visible dot does not represent the actual cutting beam.
Installation & Safety:
Disconnect machine power before installation. Verify the wiring and polarity before connecting the module. Never look directly into the red laser beam. The pointer is a positioning aid and does not replace proper laser alignment or safety procedures.
Need Help With Compatibility?
Not sure which red dot pointer fits your laser? Contact Rabbit Laser USA with your machine model and information about your existing pointer or mounting arrangement. Our technical support team can help identify the appropriate replacement component.
