CIC-2 2-Pin Aviation Connector Set – Male & Female
The CIC-2 is a 2-pin circular aviation-style connector set for compatible CO2 laser machines, water chiller connections, and electrical accessories. This two-piece set includes a male panel-mount connector and a matching female cable-end plug.
The male connector features two exposed electrical pins and a threaded mounting body for installation through an equipment panel. The female connector features two recessed contacts, a metal housing, and a threaded locking collar for securing the connection.
These connectors can be used to build or repair compatible two-wire electrical connections, including certain water chiller interlock and alarm connections. Connector dimensions, electrical ratings, and wiring must match the intended equipment.
Package includes one matching male and female connector pair. Wiring and cable are not included.
Key Features
2-Pin Connection:
Provides two electrical contacts for compatible electrical and control connections.
Male & Female Pair:
Includes a male panel-mount connector and matching female cable-end plug.
GX16-Style Construction:
Circular metal connector design commonly used in laser equipment and industrial control systems.
Threaded Locking Collar:
Helps secure the cable plug to the matching panel-mounted connector.
Panel-Mount Design:
Male connector features a threaded body and mounting hardware for installation through a suitable equipment opening.
Solder Termination:
Designed for attaching electrical wires to the connector contacts during assembly.
Chiller Interlock Applications:
Suitable for building compatible chiller alarm and interlock connections when properly wired.
Replacement Component:
Can be used to replace matching connectors or construct compatible equipment cables.
Product Specifications
Product Type
Aviation Connector Set
Model
CIC-2
Connector Family
GX16-Style Circular Connector
Contact Count
2
Connector Configuration
Male Panel Mount + Female Cable Plug
Contact Gender
Male Pins / Female Sockets
Coupling Method
Threaded Locking Collar
Electrical Termination
Solder
Connector Housing
Metal with Black Insulating Inserts
Applications
Compatible Laser Chiller Interlocks, Electrical Accessories, and Control Connections
Quantity Included
1 Male/Female Connector Pair
Rabbit Laser USA SKU
130
Compatibility
The CIC-2 connector set is intended for compatible equipment requiring a two-contact circular aviation-style connection. Applications may include water chiller interlock connections, alarm circuits, and other electrical accessories used with CO2 laser machines.
Before ordering, compare your existing connector with the replacement, including:
Number and arrangement of electrical contacts
Connector shell diameter and panel-mounting dimensions
Male and female contact configuration
Threaded coupling and connector keying
Required voltage and current ratings
Equipment wiring diagram and pin assignments
Important:
Not every laser water chiller uses the same connector or wiring configuration. A matching two-pin connection does not guarantee compatibility.
This product contains loose connector components and does not include a prewired cable assembly.
Installation & Safety
Disconnect all electrical power before installing or replacing electrical connectors.
Verify connector dimensions, contact arrangement, and electrical requirements before installation.
Mount the male panel connector securely through a properly sized equipment opening.
Solder wires to the correct terminals according to the equipment manufacturer's wiring diagram.
Use suitable wire insulation and secure the cable using the connector's strain-relief components.
Check continuity and confirm that no unintended electrical shorts are present before applying power.
Align the male and female connectors correctly before tightening the threaded locking collar.
For chiller interlock applications, verify that the complete fault-detection and protection circuit operates correctly before returning the laser machine to service.
Safety Note:
Electrical ratings and safety certifications for this specific connector set have not been independently verified. Confirm suitability for the intended circuit before installation. Never bypass a laser machine's safety interlocks.
Need Help Finding the Right Connector?
Rabbit Laser USA supplies electrical connectors, replacement components, and technical support for CO2 laser engraving and cutting machines. If you're unsure whether this connector matches your chiller or laser equipment, contact our team with your machine model and a photograph of the existing connection.
