The 2EDG 5.08mm female terminal connector provides a removable electrical connection for compatible laser engraving and cutting machine electronics. Featuring screw-terminal wire connections and a standard 5.08mm contact spacing, this connector is suitable for compatible controller boards, power distribution circuits, and other electronic equipment using matching pluggable terminal blocks.
Available in 2-pin through 6-pin configurations, the connector allows wires to be secured using individual screw terminals. Its removable design makes compatible electrical connections easier to disconnect during component replacement, servicing, and maintenance.
Key Features
5.08mm (0.200-inch) terminal spacing
Available in 2, 3, 4, 5, and 6-pin configurations
Female pluggable terminal block design
Individual screw terminals for securing wires
Removable connection for compatible circuit boards
Compact green insulating housing
Suitable for compatible machine electronics and control circuits
Convenient replacement option for matching terminal connectors
Product Specifications
Connector Series
2EDG 5.08
Product Type
Pluggable Terminal Block
Connector Gender
Female
Terminal Pitch
5.08mm (0.200 in)
Available Positions
2, 3, 4, 5, or 6
Wire Termination
Screw Terminal
Connection Style
Removable / Pluggable
Housing Color
Green
Dimensions
Varies by Pin Count
Primary Application
Compatible Electrical Control Connections
Selecting the Correct Connector
Choose the required number of pins from the available product options before ordering. The connector must match the pin count, terminal spacing, and physical mating configuration of your existing equipment.
Important:
Not all green terminal connectors are interchangeable. Confirm the 5.08mm pitch, connector orientation, mating header style, and electrical requirements before purchasing.
Disconnect equipment power before replacing electrical connectors. Ensure wires are properly secured and that the replacement connector meets the voltage, current, and wiring requirements of the equipment. Electrical installation should be performed by a qualified technician.
Rabbit Laser USA Support
Need help identifying the correct terminal connector for your laser machine? Contact Rabbit Laser USA with your machine model or a photo of your existing connector. Our technical support team can help you identify the appropriate replacement.
