DZ47-60 C25 25A 2-Pole Circuit Breaker

DZ47-60 C25 25A 2-Pole Circuit Breaker

Protect compatible laser machine electrical circuits from overloads and short circuits with the DZ47-60 C25 miniature circuit breaker.

This two-pole breaker is rated for 25 amps and AC 230/400V electrical systems. If the current exceeds the breaker’s operating limits, the breaker trips and disconnects the circuit to help protect wiring and connected machine components from overheating or electrical damage.

The linked two-pole design disconnects both poles together, making it suitable as a replacement inside compatible laser machine electrical cabinets.

Understanding the C25 Rating

The 25 identifies the breaker’s rated current of 25 amps.

The C identifies its Type C trip curve. Type C breakers are commonly used with electrical equipment that may create a brief increase in current during startup.

The replacement breaker must match the original breaker’s amperage, voltage, trip curve, number of poles, breaking capacity, terminal layout, and physical size.

Key Features

• 25A rated current
• AC 230/400V rating
• Type C trip curve
• Two-pole linked design
• Overload protection
• Short-circuit protection
• Manual ON and OFF lever
• Manual reset after a trip
• Compact design for compatible electrical cabinets
• Replacement electrical component for compatible laser machines

Product Specifications

• Model: DZ47-60
• Breaker marking: C25
• Product type: Miniature circuit breaker
• Rated current: 25A
• Rated voltage: AC 230/400V
• Trip curve: Type C
• Number of poles: 2
• Protection type: Overload and short-circuit protection
• Quantity: One circuit breaker

Standard Breaker vs. Leakage-Protection Breaker

The DZ47-60 C25 is a standard miniature circuit breaker. It provides overload and short-circuit protection but does not provide the 30mA electrical-leakage protection found in an RCBO or DZ47LE-style breaker.

Do not substitute this breaker for a leakage-protection breaker unless the machine’s electrical requirements specifically call for the DZ47-60 C25.

Confirm Compatibility Before Ordering

The C25 marking alone does not confirm compatibility. Breakers with the same amperage may have different voltage ratings, breaking capacities, trip curves, pole arrangements, terminal positions, and physical dimensions.

Compare all markings on the original circuit breaker before ordering. Do not install a breaker with a higher amperage rating as a replacement for the original part.

Contact Rabbit Laser USA with your machine model and a clear photo of the existing breaker if you need help confirming the correct replacement.

Important Safety Information

Disconnect the laser machine from its electrical supply before inspecting or replacing internal electrical components. Turning off the machine’s control switch may not remove power from every component inside the electrical cabinet.

Circuit breaker replacement should be completed by someone experienced with electrical systems. Incorrect installation may result in electrical shock, equipment damage, overheating, or fire.

If the replacement breaker trips again, do not continue resetting it. Repeated tripping may indicate an overloaded circuit, damaged wiring, a loose connection, a failed component, or another electrical fault that needs to be diagnosed.
