Solid, calibrated power for sharp cuts and clean engraving—bench-tested in Ohio and ready to slide into your Rabbit Laser USA SD-40-6040, DL-40-6040, or any 1010 mm 40 W rig.
Key Benefits
Industrial-grade build: thick-wall borosilicate glass keeps the beam steady and the spot tight.
Calibrated output: 40 W nominal (48 W peak) delivers speed without sacrificing edge quality.
Long service life: 2 000 + hours when run ≤ 15 mA at 20 – 25 °C coolant temperature.
QC-tested in the U.S.: every tube is test-fired and power-curve logged before it leaves our shop.
Protective shipping: foam-sleeved and double-boxed so it arrives intact, ready to install.
Rabbit-backed tech support: real humans, real answers—phone, email, or video call.
Technical Specs
Parameter
Value
Nominal Power
40 W
Peak Power
48 W
Tube Length
1010 mm
Tube Diameter
51 mm
Recommended Current
≤ 15 mA
Cooling
Distilled water, 20 – 25 °C
Expected Life
2 000 + hours
Net Weight
2 lb
Installation / Care Tips
Keep current below 15 mA for everyday jobs.
Use a calibrated chiller; swap distilled water every 3 months.
Align mirrors before first fire to avoid hot-spot damage.
Drain coolant if ambient temps may drop below freezing.
Need a hand? Call 513-217-5707
or email support@RabbitLaserUSA.com
—same-day answers from people who run these machines daily.
Schools, universities, and military customers:
ask about our standing discounts at checkout.
